The Jim Root Signature Pro-Mod San Dimas® Style 1 HH FR E begins with a mahogany body that has been sleekly contoured with a scalloped lower back bout for comfortable and unencumbered upper-fret access. The bolt-on maple neck is graphite-reinforced for rock-solid stability to withstand extreme climate changes, while the 12″-16″ compound radius ebony fingerboard with rolled edges and 22 jumbo frets allows for effortlessly fast playing and comfortable bends. A heel-mount truss rod adjustment wheel and Luminlay® side dots are game changers for touring musicians, allowing for pain-free neck relief tweaks on the fly and fingerboard guidance on even the darkest of metal stages.
A fearsome set of EMG® Jim Root Daemonum™ humbucking pickups combines the power of active pickups with the sensitive touch of passive pickups. Featuring exclusive white bobbins, these incredibly responsive and versatile pickups create a massive wall of crushing sound that cuts to the front of the mix. The streamlined controls consist of a three-way blade pickup switch and a volume knob.
Dive bomb for days while maintaining tuning stability courtesy of the premium Floyd Rose® 1500 Series double-locking tremolo and locking tuners.
The Jim Root Signature Pro-Mod San Dimas® Style 1 HH FR E comes in a stark Satin White finish with all-black hardware including the three-way blade switch tip and skirted Strat®-style control knob. A Charvel multi-fit hardshell gig bag is also included.
Hardware
BRIDGE: Floyd Rose® 1500 Series Double-Locking Tremolo
PICKGUARD: None
PICKUP COVERS: White
CONTROL KNOBS: Strat®-Style Skirt
SWITCH TIP: Black
HARDWARE FINISH: Black
TUNING MACHINES: Charvel®-Branded Die-Cast Locking
STRING TREES: Floyd Rose® Retainer Bar
STRINGS: Nickel Plated Steel (.009-.042 Gauges)
TREMOLO ARM: Floyd Rose® 1500 Series Locking
NECK PLATE: 4-Bolt Serialized
STRAP BUTTONS: Standard
Neck
HEADSTOCK: Licensed Fender® Stratocaster®
NECK MATERIAL: Maple
NECK FINISH: Hand-Rubbed Satin Urethane
NECK SHAPE: Speed Neck with Rolled Fingerboard Edges
NECK CONSTRUCTION: Bolt-On with Graphite Reinforcement
FINGERBOARD RADIUS: 12″-16″ Compound Radius (304.8 mm to 406.4 mm)
FINGERBOARD MATERIAL: Ebony
POSITION INLAYS: White Dot
SIDE DOTS: Luminlay®
NUMBER OF FRETS: 22
TRUSS ROD: Dual-Action with Wheel
TRUSS ROD NUT: Heel-Mount Truss Rod Adjustment Wheel
STRING NUT: Floyd Rose® 1500 Series Locking
NUT WIDTH: 1.6875″ (42.86 mm)
NUT MATERIAL: Floyd Rose® 1500 Series Locking
Electronics
BRIDGE PICKUP: EMG® Jim Root Signature Daemonum™ Open-Coil Active Humbucking
NECK PICKUP: EMG® Jim Root Signature Daemonum™ Open-Coil Active Humbucking
PICKUP CONFIGURATION: HH
CONTROLS: Volume
SWITCHING: 3-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
SPECIAL ELECTRONICS: Active Electronics
Body
BODY: Mahogany
BODY FINISH: Satin
BODY SHAPE: San Dimas® Style 1
BODY STYLE: Solid Body
BODY MATERIAL: Mahogany
